Jinko NEO N Type Bifacial 580W 585W Solar Panel

The Jinko JKM585-N-72HL4RBDV is a cutting-edge solar panel produced by JinkoSolar, a leading global manufacturer in the solar energy industry.

  • Power Range:

    575W-585W
  • Max. Efficiency:

    22.64%
  • Dimensions of Module L*W*H:

    2278*1134*30mm
  • Weight:

    32 kg
  • Number of Cells:

    144 (6 * 24)

New Products

Jinko NEO N Type Bifacial 580W 585W Solar Panel



the Jinko JKM585-N-72HL4RBDV solar panel offers exceptional power output, efficiency, durability, and reliability, making it an ideal choice for commercial, industrial, and utility-scale solar installations.

  • --Model: JKM585-N-72HL4RBDV
  •
  • --Dimensions: 2094 x 1038 x 35 mm
  •
  • --Weight: Approximately 24.5 kg
  •
  • --Cell Type: Monocrystalline N type
  •
  • --Cell Arrangement: 72 cells (6x12)
  •
  • --Power Output: This panel is engineered to deliver an impressive power output of 585 watts under standard test conditions (STC), making it a high-efficiency option for solar energy systems.
  •
  • --Efficiency: With its advanced monocrystalline N type cells, the panel achieves remarkable efficiency, typically above 20%. This enables it to convert a significant portion of sunlight into usable electricity, optimizing energy production.
  •
  • --Durability: Designed to withstand harsh environmental conditions, including extreme temperatures and weather elements, the panel has a robust construction. It boasts a high snow load capacity of up to 5400 Pa and a wind load capacity of up to 2400 Pa, ensuring reliability and longevity.
  •
  • --Warranty: JinkoSolar offers a reliable warranty, typically covering 25 years of performance guarantee and product warranty. This underscores the manufacturer's commitment to providing customers with long-term peace of mind and assurance of product quality.






Electrical Parameters (STC*)

Module model

JKM575NN-72HL4RBDV

JKM580NN-72HL4RBDV

JKM585NN-72HL4RBDV

Maximum Power (Pmax/W)

575

580

585

Open circuit voltage (Voc/V)

51.27

51.47

51.67

Short circuit current (Isc/A)

14.31

14.37

14.43

Peak power voltage (Vmp/V)

42.44

42.59

42.74

Peak power current (Imp/A)

13.55

13.62

13.69

Module Efficiency (%)

22.26

22.45

22.64

Power Output Tolerance (W)

0~3%

Temperature Coefficient of Isc

+0.046%/°C

Temperature Coefficient of Voc

-0.25%/°C

Temperature Coefficient of Pmax

-0.30%/°C

Standard test conditions

STC:AM1.5    1000W/m²    25℃




Why Choose Jinko Solar Panel?


JinkoSolar is recognized for its high-quality solar products and innovative technologies, making the JKM585-N-72HL4RBDV panel a preferred choice among developers, installers, and project developers globally. Its reliability, performance, and warranty make it a trusted option for solar energy projects of various scales and applications.






Applications of Jinko JKM-N-72HL4RBDV PV Module

Commercial/Industrial: The Jinko JKM585-N-72HL4RBDV is well-suited for commercial and industrial-scale solar installations, offering a high-power solution to meet the energy needs of businesses and enterprises. It enables significant cost savings and enhances sustainability efforts.

Utility-Scale: With its exceptional power output and efficiency, the panel is also suitable for utility-scale solar projects, supporting utilities in generating clean energy on a large scale and advancing renewable energy initiatives.




Global Presence of Jinko Solar

The Jinko JKM-N-72HL4RBDV solar panel has gained popularity across different markets globally. Its high efficiency and reliability make it suitable for a wide range of applications, including utility-scale solar farms, commercial rooftops, and residential solar systems. It has been extensively used in countries with a growing demand for renewable energy, such as the United States, Germany, Australia, and China.
