Meter marking - easy installation & UV. ozone and hydrolysis resistant.
Brand:
SunEvoRated voltage:
DC 1500 V AC Uo/U：1.0/1.0kVMax .permitted voltage:
Uo 1800 V DCInsulation resistance:
1000MΩ/KMTest Voltage(AC):
AC 6. 5kV, 50Hz, 5 minTemperature range:
-40°C to +90°C, Max.temp. at conductor + 120°CShort circuit temperature:
250°C for 5 sFlame-resistant test:
acc.to EN 60332-1-2 25years
Advantages
-Double insulated Electron-beam- cross-linked compounds
-Compatible to all connectors
-Halogen free, flame retardant
-Flexible, easy to strip
-Moisture-proof, sun-proof, cold-proof, UV-proof
-Superior ability to prevent water, ozone, acid, and salt corrosion
-Flame retardant, environmentally friendly, long service life
Construction
-Conductor: Tinned fine copper strands acc.to VDE
0295/IEC 60228, Class 5.
-Insulation:XLPO, flame retardant, halogen free
electron-beam cross-linked.
-Jacket:XLPO, flame retardant, halogen free,
electron-beam cross-linked
-Insulation color:Black and red
-Jacket color:Black with red strip
DC PV Cable Meet Certifications And Application standard
TUV 2PfG 1169/08.2007 PV-F UNE 211 23:UNE 20.460-5-52 UTEC 32-502
FAQs:
Q1:How long is the delivery time?
A: The delivery time is generally 5 working days after receiving the advance payment, if there is stock, it can be shipped immediately；
Q2: Does it support door-to-door service？
A：Yes, we have freight forwarders with many years of rich experience in the industry, who can deliver goods to the door and help customers clear customs and pay taxes;
Q3:How many years of warranty and after-sales service are provided?
A:We provide a unified 10 years warranty for DC solar cables.
Cables carry the DC power generated at the panel back to a collection point or device. During the power transmission process, DC power can flow directly with minimal loss.
It's the connecting bridge between solar panels and inverters and is crucial for the efficient transmission of photovoltaic power.
Photovoltaic special DC cable is an indispensable part of the photovoltaic power generation system. They have a variety of advantages and features that allow them to maintain stable working conditions under harsh environmental conditions.
HJT solar cell is a new generation superior bifacial solar cell made out of an N-type wafer, which combines the merits of crystalline silicon and thin-film technology to form a single composite structure. As one of the most effective cell passivation technologies in the market, HJT ensures that solar cells deliver high efficiency and great power even in hot climates.
A charge station, also known as an electric vehicle (EV) charging station or an EV charging point, is a dedicated infrastructure that supplies electricity to recharge electric vehicles. It is similar to a fuel station for conventional vehicles but specifically designed for chargings.
The Longi LR5-54HTB435M module is a high-performance solar module manufactured by Longi Solar, a leading global supplier of solar panels. This module is known for its exceptional quality, advanced technology, and efficient power generation capabilities.
The deep cycle AGM battery is known for its long cycle life, providing reliable power for extended periods without the need for frequent replacement. Its design includes robust plates that allow for deeper discharges compared to conventional batteries, making it highly efficient in demanding applications. The battery's spill-proof construction ensures safe operation in any position, making it suitable for a variety of installations. It also offers high energy density, enabling more power to be stored in a compact size. Additionally, this battery performs well in both high and low-temperature environments, ensuring consistent performance in extreme conditions. Its low maintenance requirements and superior charge retention make it an ideal choice for energy storage systems and off-grid solutions.
The EVO 5N Series, featuring HJT (Heterojunction with Intrinsic Thin-layer) technology, represents a groundbreaking fusion of the best attributes of both crystalline silicon and thin-film solar cells. The outcome is nothing short of remarkable: a solar technology with exceptional energy conversion efficiency.
