APsystems Micro Inverter Single phase Solar 600W 700W 800W 900W APS AP System PV Microinverters

The APSystems EZ1-M microinverter is an innovative and efficient solution for residential and commercial solar energy systems. It offers a range of features that ensure optimal performance, ease of installation, and advanced monitoring capabilities.

  • Model:

    EZ1-M / EZ1-H
  • Recommended PV Module:

    300Wp-730Wp+ / 410Wp-760Wp+
  • Output Data (AC):

    600VA(3)/799VA / 960VA
  • Communication:

    Built-in Wi-Fi and Bluetooth
  • Weight:

    2.8kg / 3kg

New Products

APsystems Micro Inverter Single phase Solar 600W 700W 800W 900W APS AP System PV Microinverters



The EZ1-M microinverter stands out due to its compact size and high efficiency. Its small form factor allows for easy integration and installation, making it suitable for various rooftop configurations. The microinverter utilizes MPPT (Maximum Power Point Tracking) technology to extract maximum power from each solar panel, ensuring higher energy production and increased overall system efficiency.




Important Specification of APSystems Single Phase Micro-Inverter

Model
EZ1-M
EZ1-H
Region
EMEA
Input Data (DC)
Recommended PV Module Power (STC) Range
300Wp-730Wp+
410Wp-760Wp+
Peak Power Tracking Voltage
28V-45V
Operating Voltage Range
16V-60V
Maximum Input Voltage
60V
Maximum Input Current
20A x 2
Isc PV
25A x 2
Output Data (AC)
Maximum Continuous Output Power
600VA(3)/799VA
960VA
Nominal Output Voltage/Range(1)
230V/184V-253V
Nominal Output Current
2.6A(3)/3.5A
4.2A
Nominal Output Frequency/ Range(1)
50Hz/48Hz-51Hz
Default Power Factor
0.99
Efficiency
Peak Efficiency
97.3%
Nominal MPPT Efficiency
99.5%
Night Power Consumption
20mW
Mechanical Data
Operating Ambient Temperature Range(3)
-40 °C to +65 °C
Storage Temperature Range
- 40 °C to + 85 °C
Dimensions (W x H x D)
263mm x 218mm x 36.5mm
263mm x 218mm x 37mm
Weight
2.8kg
3kg
DC Connector Type
Stäubli MC4 PV-ADBP4-S2&ADSP4-S2
Cooling
Natural Convection - No Fans
Enclosure Environmental Rating
IP67
Features
Communication
Built-in Wi-Fi and Bluetooth
Maximum units connected(4)
2
Isolation Design
High Frequency Transformers, Galvanically Isolated
Energy Management
AP EasyPower APP
Warranty
12 Years Standard; 20 Years Optional
Compliances
Safety, EMC & Grid Compliances
EN 62109-1/-2; EN 61000-1/-2/-3/-4; EN 50549-1;DIN V VDE V 0126-1-1; VFR; UTE C15-712-1; CEI 0-21;UNE 217002; NTS; RD647; VDE-AR-N








Key Advantages



One of the key benefits of the EZ1-M microinverter is its advanced monitoring capabilities. It comes equipped with APSystems' powerful EMA (Energy Monitoring and Analysis) software, which enables real-time monitoring of individual panel performance. This allows users to identify any underperforming panels or potential issues quickly, maximizing system efficiency and minimizing downtime.



Installation of the EZ1-M microinverter is straightforward and hassle-free. It utilizes a plug-and-play design, allowing for easy connection between the microinverters and the solar panels. This simplifies the installation process, reduces labor costs, and provides flexibility in system design.



Safety is a top priority for APSystems, and the EZ1-M microinverter incorporates enhanced safety features. It is built to comply with international safety standards and includes features such as rapid shutdown capabilities, reducing the risk of electrical hazards during maintenance or emergency situations.



The EZ1-M microinverter is designed for long-term reliability and durability. It is built with high-quality components that can withstand various weather conditions, ensuring consistent performance over the lifespan of the system. Furthermore, the microinverter is backed by APSystems' warranty and support, providing customers with peace of mind and reliable after-sales service.



Another advantage of the EZ1-M microinverter is its system flexibility. It allows for module-level optimization, meaning that each solar panel operates independently, maximizing energy output even when individual panels are shaded or affected by other environmental factors. This flexibility ensures that the system performs at its best under diverse conditions.






Monitoring Platform



APPLICATION FOR CONFIGURATION& COMMISSIONING



Free download on APP Store and GOOGLE Play, the APsystems ECUAPp becomes the interface of the ECU-B, ECU-R or the ECU-C allowing configuration and quick setup of the installation
