Lead Carbon Battery 12V 250Ah 12 Volt Leoch Lead Carbon Batteries

LC series lead-carbon batteries use functional activated carbon and graphene as carbon materials, which are added to the negative plate of the battery to make lead carbon batteries have the advantages of both lead-acid batteries and super capacitors.



  • Brand:

    SunArk
  • Cells Per Unit:

    6
  • Voltage Per Unit:

    12V
  • Design Life:

    20 years (Float charging)
  • Standby Use Voltage:

    13.6V~13.8V @25°C
  • Cycle Use Voltage:

    14.2V~14.4V @25°C
  • Operating Temperature Range:

    Discharge: -15°C~50°C Charge: 0°C~40°C Storage: -15°C~50°C
  • Normal Operating Temperature Range:

    25°C ± 5°C
  • Self Discharge:

    Monthly Self-discharge ratio is less than 3.5% at 25°C.
  • Container Material:

    A.B.S. UL94-HB UL94-V0 Optional

New Products

Product Parameter&Application:



Product Parameters:
Terminal: M6/M8 Copper Insert
Cycle Use Voltage: 2.30~2.33Vpc(25 °C)
Temperature Compensation : -4mV/°C/Cell
Operating Temperature Range: 15 °C~30°C
Max. Operating Temperature Range:-20~60°C
Applications:
Home energy storage system
Smart power grid and micro-grid system
Distributed energy storage system
Solar and wind energy storage system
Solar power generation grid or off-grid energy storage system
Generation and battery hybrid energy storage system

Environmental Characteristics:



(1) It is recommended to store at an ambient temperature ranging from -20°C to +50°C.

(2) When the battery is stored, the battery must be fully charged. As part of the capacity will be lost due to self-discharge during transportation or storage, please recharge before use.

(3) For long-term storage, please recharge regularly (it is recommended to recharge once every six months).

(4) Please store in a dry and well-ventilated place with low temperature

Lead Carbon Battery Technology:



What problems can be solved by Lead-carbon technology battery?

PREVENT SULFATION; FAST RECHARGE/DISCHARGE .

The main application of Lead-carbon battery is Energy Storage. Lead-carbon battery has the fast recharge and big current charge/discharge function to offer stable performance. Adding carbon is to eliminate the polarization of the negative electrode. Under the same process conditions, the charging voltage of lead acid battery without carbon can reach to 16V ~ 17V, and the lead-carbon battery voltage is 15.5V ~ 16.5V only. Our lead-carbon technology battery's recharge voltage is controlled at approx 14.6V, about 1V lower under the same process than those with less carbon. Furthermore, lead-carbon offered fast recharge function, because of its electrical conductivity and thermal conductivity, which can save 40% ~50% charging time.

  1.

Prospects advantages of lead-carbon battery:

Lead-carbon batteries are the most advanced technology in the field of lead-acid batteries, and are also the development focus of the international new energy storage industry, with very broad application prospects. Energy storage battery technology is one of the key technologies restricting the development of new energy storage industry. Energy storage fields such as photovoltaic power station energy storage, wind power energy storage and grid peak regulation require batteries to have the characteristics of high power density, long cycle life and low price.
Lead-carbon batteries, lithium-ion batteries and flow batteries are the three major development directions of new energy storage batteries.
Among them, the cost of lithium battery is relatively high, and the consistency problem still exists; the cost of liquid flow battery is also high; and lead-carbon battery is a relatively practical and feasible energy storage technology route. Ordinary lead-acid batteries have the advantage of low cost, but their short cycle life leads to higher energy storage costs per unit of time. Due to the addition of activated carbon, the lead-carbon battery prevents the sulfation of the negative electrode, prolongs the battery life, and reduces the cost per unit of use. It has great potential for development in the field of new energy storage.
Lead-carbon batteries have been greatly improved in terms of cycle life and power charge-discharge performance under partial state of charge. Coupled with advantages such as cost, the application of lead-carbon technology in various energy storage systems has been greatly improved.
China is still in the initial stage of energy storage industrialization, and is in a state of coexistence of various energy storage technologies. Whether it is lead-carbon batteries, lithium batteries, or flow batteries, they will have different advantages in different application fields. Mainstream energy storage technologies will be chosen by the market.
